Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)

Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 214

An illustration from Appleton's dictionary of machines, mechanics, engine-work, and engineering, 1861, leaf 214 — Fig. 628.—Section through Girder, showingthe Stays to Stiffen the Top Plate.. l._»___

Mechanical engineering

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
