Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)

Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 231

An illustration from Appleton's dictionary of machines, mechanics, engine-work, and engineering, 1861, leaf 231 — nd packed for sale or transportation. CALENDER WITH FIVE ROLLERS, Designed and Constructed by Messrs. A. More and Son,Glasgow. Fig. 644, an end view; Fig. 643, a side elevation; the same letters of reference denote thesame parts in each view. AAA, three cylinders or rollers made of paper, the… … Scale.—l-41h inch = 1 foot

Mechanical engineering

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
