Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 264
l c on the oblique axis d, (shown by dotted lines) of the pinion e upon the lower end of thesame axis which turns the wheel /, upon the under feed roller. The lever mechanism of the stripperknife i, is operated by the pulley t driven by the band s from the pulley r on the drum shaft. The ope-ration… … Front View. Scale.—5 inches = 8 feet.
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
