Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 322
a section of it, and the lever beneath it. It alsoexhibits the chain g, and various parts adjacent thereto. The cam i2 is made to act upon and depress a lever Tc1, whose fulcrum is at P.carries a roll m?, applied to the side of its inner end, and resting on the chain g\ Now in order that the… … The said lever
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
