50° 100° 150° … The additional scale, under this figure, shows the position of the piston corresponding to any givenposition of the crank: thus, in fig. 5, when the crank is at 140°, the piston has moved through -fc ofits stroke, and so on. The lines representing the forces are measured by a scale, which is…
