Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 847
le being established, it may be adapted conveniently to practice by constructing a bevelof brass, of the requisite form, the angle at T being 75-J- degrees : the side T 3 may for convenience begraduated into a scale of quarters of inches as in the Figure; and these divisions may be further… … GEERING. 837 the radius of the wheel in inches upon the reduced scale. Thus in the figure the radius A T is threeinches long, and the point 3 is found at 3 of the scale. To draw the curves of the other teeth, describe from centre A with radius A 3 th<; circle p q, dottedin Fig. 2055, and falling…
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
