Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 146
from getting across to the angle, and the plates into which they are fixed then getpressed ont by the force of the steam. It would he a good plan to cover these rivets with anotherperforated plate placed above them, the holes in which should be of a somewhat smaller diameter thanthat of the tubes.… … 7T = i 24 feet 3 inches. SciLE.—9-128th inch = 1 foot. Horizontal Section. 24 feet 3 inches. Scale.—9-138th inch = l foot. Longitudinal Section.
Mechanical engineering · Mechanics · Engineering
