etting across to the angle, and the plates into which they are fixed then getpressed out by the force of the steam. It would he a good plan to cover these rivets with anotherperforated plate placed above them, the holes iD which should be of a somewhat smaller diameter thanthat of the tubes. Figs.… … A^ 24 feet 3 inches.Scale.—9-128th inch — 1 foot.Horizontal Section. 24 feet 3 inches. Scale.—9-128th inch = 1 foot. Longitudinal Section.
