wheel c on the oblique axis d, (shown by dotted lines) of the pinion e upon the lower end of thesame axis which turns the wheel /, upon the under feed roller. The lever mechanism of the stripperknife i, is operated by the pulley t driven by the band 3 from the pulley r on the drum shaft. The… … Front View. Scale.—5 inches = 8 feel.
