Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 121

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 121
416. FLANGED EXPANSION JOINT.—Used in pipe lines to take up the change inlength due to difference in temperature. 114 STEAM APPLIANCES. … 417. AUTOMATIC RELIEF VALVE.—Thevalve is kept closed by a crank attachment to thespindle and weighted lever outside. Excess of press-ure raises the stem and discs, throttling the passageof steam and relieving the back pressure.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
