lever N, which eye-piece fits on to the shaft I. Y is a drum which carries the chain Z over the rollers1, and being fastened to the sliding-frame K, gives motion to the same. The chain-drum Y receivesits motion through the bevel-wheel 2, which works into the bevel-wheels D] D1 on the main-shaft Con… … of the cnam-drum Y. 11 are clutch-boxes which slide on keys on the main-shaft C, and are workedby forked levers 8 8, which again are actuated by the handles 9 9, as seen in the front view of the ma-chine, Fig. 4005. a a are circular saws which are fixed to the shafts b b, to which shafts motion is…
