Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 267
h account it wouldbe designated by the iron-founder a drawback, by the brass-founder & false core. All the patterns in the mould, Fig. 789, could be extracted from each half of the mould, becausenone of them encroach beyond the perpendicular line, or {hat in which the mould is lifted; a and… … in Fig. 790 being undercut, the division of the mould into two parts only would be impracticable, andfalse cores or subdivisions would be required in the manner represented, the construction of which willbe hereafter detailed. Extending these same views to a more complex object, such as ti bust, it…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
