Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 331
view of the lower elevator framing. Figs. 985 to 990. These figures give minute representations of the construction of the creeper.Figs. 985 and 986 are a section and external view combined to show the mode of junction of the differ-ent lengths; Fig. 987 is a transverse section of the creeper-box;… … General Description. The Framing.—A strong cast-iron standard or framing A A, securely bolleuto a stone foundation by two holding-down bolts, incloses the principal part of the driving and adjustinggeering for each pair of stones. It is made somewhat in the form of an oblong box, and is traversed…
