Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 364
e of the tool forms the second side of the angle, and allowing for exaggeration, bothas to excess and deficiency, the diagram may be considered to represent the edges of the following tools. [abed, Splitting and Paring Tools, proceeding from A to B.] a, The axe. or the cleaver for splitting. 6, The… … c, The turning chisel for soft wood, the chipping chisels for iron, stone, <tc. d, The joiners chisels and carving tools, used with the bevels downwards, the joiners planes, thecross-cut chisel for metal, and some other metal tools. [ef, Scraping Tools, proceeding from A to B.] e, Alien single,…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
