Training in wood-work, designed for use in manual training and technical school; consisting of three parts: carpentry, wood-turning and pattern work (1902)
Tate, James M. (James Murray), b. 1852 · Minneapolis, Minn., School Education Co · leaf 103
Fig. 172. ished, the ring will be complete. Before removing the workfrom the face-j)late, mark a line at the point marked A, in Fig.173, with a sharp point of the compasses. This line is for the … Fig. 173. purpose of centering the hub, that is, locating its center onthe arms after they are inserted. Remove the ring from theface-plate and it is ready for the arms. Dress out a piece7-16 inch in thickness and 1^/2 inches wide and of properlength for the arms. Set the compasses to the radius of…
Woodwork (Manual training)
