y I. Fig. 1136 represents a section of the dock in the receiving-chamber, with a line of battle-ship resting onthe keel-blocks and shores. The exhaust culverts are shown at E. In all of t>.ese drawings the most im-portant dimensions are marked in feet and inches, which obviates the uecessitv of… … Description.—A is a pulley, Fig. 1159, which receives the power from the driving-pulley, winch is trans-mitted through the geers C D and E to the pulley B, thence to the driving-machine. The pulleys are e\i%>side of the frame, the geers 1E inside of the frame, and supported by it; the…
