tion of the dock in the receiving-chamber, with a line of battle-ship resting onthe keel-blocks and shores. The exhaust culverts are shown at E. In all of these drawings the most im-portant dimensions are marked in feet and inches, which obviates the necessity of any further description.… … Description.—A is a pulley, Fig. 1159, which receives the power from the driving-pulley, which is trans-mitted through the geers C D and E to the pulley B, thence to the driving-machine. The pulleys are out-side of the frame, the geers C E inside of the frame, and supported by it; the intermediate…
