Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 530
the large engines. v v v, a combination of levers and rods for working. to, the injection-valve. x, the blow-through or snifting-valve, and i, thethrottle-valve. The connections for each valve aredistinctly shown in the elevation. y, a graduated cam on the intermediate shaft forworking the…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
