ests against the guide,and so connected, either with the guide-bar or some other part of the machinery, that at the time of thecutting motion it will move forward, that its bevelled surface may be brought in contact with the guideand give a lateral motion to the guide-bar, to relieve the cutter… … In the accompanying figures, a represents the main frame of the machine, to the inside of which isadapted a frame b that carries the spindle c of an index-plate, made in the usual manner. This frameb is secured to the main frame by the bolts dd that pass through elongated holes ee in the side…
