Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)

D. Appleton and Company · New York : D. Appleton and Co. · leaf 80

An illustration from Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes, 1873, leaf 80 — the rest-bar TT, to move upwards horizontally, similar to the action of a parallel rule, and raisethe rollers F or B out of, or into their respective places, by enabling the rollers to be rolled alongthem, when disengaged from their bearings or seats, and carefully lowered into their places, in… … the connecting-rods KK, when the pressure will bo removed from the lower rollers, and wnich willenable them to be raised to the required height, so as to transfer them from one seat or bearing toanother, and thus allow the fabrics to be changed by removing those already having undergone theprocess,…

Mechanical engineering · Mechanics · Engineering
