Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 201
6, the driving cone-pulleys, loose on the spindle of the lathe and fast with the pinion p, Fig. 253S.h, a spur-wheel, fast on the back shaft, and i a pinion also fastened on the same. «•, a wheel fast onthe lathe-spindle, geering with the pinion i. c, is the chuck or face-plate ; this admits of…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
