he shipper connecting-rod h, (which looks Uke an n,)Figs. 2252 and 2253, has a liinge-joint t, to allow it to be lifted from the shipper g. The small bevel-wheel J, on the shaft K, is one-third of the diameter of the driving-wheels, when there are three spindleion the table, and therefore makes the… … To explain its operation. Fig. 2251 exhibits a different arrangement of mechanical parts from the sec-tion views, but they are just the mechanical equivalents to accomplish the same thing. Heddle orharness making is the formation of eyts by two cords being knotted together. These eyes must beformed…
