Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 248
at the ends, and 19 in the middle; this is bedded on felt to the lowermost cast-iron bar,and securely fixed by li inch bolts. The boiler-plates which line both sides of the gates are so ar-ranged that they break joint; for 6 feet in height their thickness is of an inch—above, only Yj ; theyoverlap… … 244 LOCOMOTIVE ENGINE. anchors, which are of cast-iron, 3^ inches square; they are dovetailed into the quoins, and run with leadThe roller segments or railways are 10 inclies in breadth by 1^ inch, 4 inches in thickness; they ar«6unk into the stone, and securely bolted, and bedded with felt and…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
