Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 521
lvania, called the anti-friction cam: themachines are extensively made at Holyoke, Massachusetts. The principle of their construction willbe readily understood from the following cuts and description : Fig. 3102 represents the elevation, Fig. 3103 a section, and Fig. 3104 the combination of cams on… … PRESS, ANTI-FRICTION CAM. 515 wheels; D D are sections of the follower and bearing of the sectors. The axes of the sectors are angu-lar or edge shaped. The centre roller B is made to revolve by means of the winch or lever E, which carries by its tractivequalities the two eccentric wheels A A, the…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
