w looking upon the frame K, the guide-rods RR and chuck L bemgremoved Fig. 3277 is an end view looking upon tlie frame N. Fig. 3278 is a general side elevation of the machine corresponding with the plan in Fig. 3275. Fig. 3279 is a face view of the chuck L, seen also in Figs. 3275 and 3280. Fig.…
