At the top of the chimney A is placed an air-chamber B. over which is placed a deflecting cone C, Inthe form of a funnel, with tiie outer edges turned down all around uniformly, to reverberate the steam,gases, and particles, and throw them into a series of curved and inclined flues D, surrounding…
