Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 661
over which the stave passes, which raised pieces together with the concave rollersD D form throats or slots just the thickness of the stave, and through which the stave is made to passH, a guide-piece to conduct the stave to the second saw. I, a Ught spring to press the slave against… … IS uudeineath, and does not appear in the engraving except at J. L L, movable fninie that supportsthe saw, and that is attached to and acted upon by lever B to adjust the saw to tlie width of the stave.M, journal-box. P P, pulleys to drive the circular saw. 0, pawls, or hold-fasts, to lever 0. N N,…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
