the returner. SUGAR BOILERS. tViU Q, a stroDg spur-pinion on the gudgeon of the top-roller. On its face are also cast llie jirojectioo* g g q, engaging with similar projections on the coupling-box of the driving-shaft. K S, spur-pinions on the gudgeons of the lower roUere, geering with the pinion… … Fig. 3377 represents a five-roller sugar-mill built by Nellius in Fiance for the French colonies.The mills used for grinding the cane are generally placed ten to twelve feet from the ground, in ordeito give sufficient fall for the juice to flow into the juice-boxes, and from them into the kettles.
