A slow-running steelsaw blade lubri-cated by dippingin an oil box. Thesaw is automatical-ly fed to the plateby a worm gear,but has a quickreturn by the handwheel. 1372. COMBINED PUNCHAND SHEARS in one frame anddriven from one shaft. Each con-trolled by a treadle. 1373. SUSPENDED SWING TREADLE.—The… … 1374. POWER RUMBLING MILL, for cleaning sand from castings, pol-ishing metal articles by tumbling withsand, charcoal, leather scrap, or any-polishing powder. 1375. CENTRIFUGAL SEPARATOR, for removing oil fromiron chips and turnings. The iron pan A is fixed to the spindle and pulley. The unequal…
