Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 695
umn y to feed the strilie-pan D. The vapor arising from the second pan B passes through column n and steam-chest A-, and up throughthe column o, to boil the pan C. The vapor from C D passes through the columns p 2 through thehorizontal pipe s, and brings the vapor to the condenser s, wliere it is… … The waste water of the first pan A comes down through a pipe into an air-tight chest in tlie bot-tom-plate of the pumping engine, from which the force-pump u taies it and sends it back to the steam-boilers. The waste water of the second and third pans, which is the condensed water of the vapor…
