in the usual manner. The ends or points of the moveable tonguerails, D and D, being made and constructed, as represented by thedotted lines, in addition to the full lines in the plan, fig. 1, and also byfigs. 2 and 3; fig. 2 being an elevation of the tongue rail D, showingthe inclination of the top…
