sses are much facihtated by selecting instruments the most nearly in correspondence withthe required shapes. Rectilinear surfaces, such as cylinders, cones, and planes, whether external orinternal, necessarily require tools also with rectilinear edges, which are sloped in various ways as re-gards… … The right-side tool. Fig. 3498, cuts on the side and end, the dotted lines being intended to indicate theandercut bevel of the edge—so nameil because it cuts from the right hand towards the L-ft. The Irft-siJttool. Fig 3499, is just the reverse. The flat-tool. Fig. 3500. cuts on both sides and on…
