Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 782
TOOL, PORTABLE DRILLING—By Nasmyth, G.iskell & Co., Manchester, tig. 3652 is a sideelevation of the machine; Fig. 3653, a front view. Fig. 3654 is a partial section through the axis of the drill-spmdle. Fig. 3655, a cross-section above the table N, showing the form of the frame A. A. This frame…
Mechanical engineering · Mechanics · Engineering
