ion • iow of tho under side of the ma. i which the tables that carrj the gp to n volve, II HEDDLES. A is the heddle-beam. BBBB are revolving spool-frames or tables. C represents the spool-spin-dles, a are slots in the spool-tables. Each table has six slots or spindle recesses, but only three… … fellow-table, as seen in Fig. 2253. The tables BB constitute one pair, and the tables B 2, B 3, another,forming two distinct harness, one on each side on two beams, but driven by the same geering. Theyarn is put on the spindles 0, and passes through a hole in the top of the livers D, or over a…
