Fig. 2655 is a back view of the outer end of one of the shuttle-boxes, showing the manner in whichJie lever U and its appendages operate. The piece of wood or metal V which is raised and lowereuby the action of the lever U, and which is represented as resting on the picker W, will, when the…
