itted to the groove in the rim of said table. Said yoke/has a vertical shot formed throughit, the longitudinal centre of which is in continuation of a right line extending horizontally outwardsfrom the centre of the axis c. By means of a stud 23 which extends upwards in a perpendicular… … to the right or left hand, it communicates a corresponding movement to said yoke. The lever g l?connected by a vertical axis 24 to the fixed frame, as is shown also at 2-4 in Figs. 30C3 and 3064; ithas a broad part in which is a slot or opening of sufficient dimensions to allow the shaft c to pass…
