Appleton's dictionary of machines, mechanics, engine-work, and engineering (1869)
New York, Appleton · leaf 893
as divided the turbine,as before intimated, horizontally into two or three stages, by means of thin plates of sheet-iron placedin the channels. The curvature of the water channels of the turbineand of the guide-curves in the fixed crown, may bedetermined by the following mode. Describe the… … Vhao = From the centre o draw o d, making with ( \. f YfW \ \ M a o an angle doa = dao; and from the point e, whereo d cuts the circle representing the tube or pipethrough which the spindle of the turbine ascends,take c b parallel to oa; from b draw 6 c perpendicu-lar to a d, and from d draw dc…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
