Applied mechanics: an elementary general introduction to the theory of structures and machines (1884)
Cotterill, James H. (James Henry), 1836-1922 · London, Macmillan and co. · leaf 578
B B A A pencil when the cylinder communicates with the atmosphere. A Ais the vacuum line laid down on the diagram at a distance belowBB, which represents the pressure of the atmosphere, as found bythe barometer, reckoned on the scale of pressures, Then on the PLATE XI. Fig. I … To face page 530. Ui * * V •/•* . *£<$7.Ni en. XXL ART. 275.] THERMODYNAMICS. 531 same scale any pressure shown by the indicator is the absolute pres-sure when measured from A A. The figure drawn is a closed curve bearing a general resemblance tothe diagram Fig. 195, which was drawn to represent…
