Duncan, J. (John), d. 1941 · London, MacMillan and co., limited · leaf 104
(b) FIG. 108.—Wind acting on the left-hand side of the truss. TABLE OF FORCES. Name of part. Force in Ib. Name of part. Force in Ib. Push. Pull. Push. Pull. Reaction AB 1200 AH 1870 Reaction EA,\ AL 320 inclined / 1020 AN — 400 CH 2300 • — HK IOOO — DK 2300 — KL — 1550 EM 1400 — LM — 100 EN 1400 —… … FIG. 109.—Combined dead and wind loads on the truss. TABLE OF FORCES. Name of part. Force in Ib. Name of part. Force in Ib. Push. Pull. Push. Pull. Reaction AB 2560 — AH — 5830 Reaction GA, }inclined / 3350 — AL AN — 39007450 CH 6400 — HK 900 — DK 5950 — KL — 2100 EM 7100 — LM — 3840 FN 7500 — MN…
Mechanics
