G2, G3 and G4 are found D … BFIG. 634.—Lines of pressure for a reservoir wall. as before, and the lines of weight passing vertically through themgive mlt m2, mB and m4 on the line of pressure for reservoir empty.D u a s A Rj of Pj and Wl is found bymeans of the triangle offorces, and a line drawn fromthe point of intersection…
