resent the shearing force on the cantilever at P, that is, the curve of slope in Fig. 156 is the shearing force curve in Fig. 157. Again, at any section Pof the cantilever (Fig. 157)the bending moment is pro-portional to the area of thefigure PHKB multiplied byx, the horizontal distance ofG, the… … FIG. 157. . the cantilever at P, that is, the curve of deflection in Fig. 156 is thebending moment curve in Fig. 157. Hence having constructed the bending moment diagram for anysystem of loads, thecurve of slope andthe deflection curvemay be constructedby the rules for con-structing the shear-ing…
