is done as follows: With the boardset up, leveled and oriented at A, Fig. 1 Y, as above, draw a line in thedirection of the desired point B, Fig. 1 X, and then move to B, counting MILITARY SKETCHING. 167 strides, keeping record of them with a tally register, Fig. 5, if one is avail-able. Set up the… … (Sketching Case)—Figure 3. 168 CHAPTER VII. as at A. With the scale of the sketchers strides on the ruler, Fig. 3, layoff the number of strides found from A, Fig. 1 Y, to B, Fig. 1 X, andmark the point (b), Fig. 1 X. Other points, such as C, D, etc., would belocated in the same way.
