San Francisco : Architect and Engineer, Inc · leaf 275
Interior view of inlet stack, looking up through the stackfrom a test cell floor, showing how Fiberglas bats ore in-stalled between metal sheets, and spacing of baffle plates. JANUARY, 1942 33 … (Top) Exterior view of test stand building. Inlet stacks for the four test cells are on thecorners of the structure; outlet stacks in the center each serve two test cells. (Above—left)Exterior view of inlet stacks. (Above—right) Interior view of test cell, showing height fromthe cell floor thot…
