AIH UISTRIBIJTIDIV . . . … Metal cones of this Anemostat oir-diffuser are designed so that thepassage of incoming air (black arrows) through them siphons a seriesof counter-currents of room air (white arrows) back into the cones.Simultaneously, air-expansion within the cones greatly reduces theincoming air-velocity, in this…
