CONCRETE SLAB —WALLS … TABLEASSEMBLED With steel reinforc-ing and sash to bepoured. WELDING RETAINING PLATE (right) on reinforced rodsfor fixed anchorage. Plates hold tension on rods after formsare stripped. TABLE filled with concrete being placed by special vibrat-ing screed. Table also vibrates to help proper…
