The architect, or practical house carpenter : Illustrated by sixty-four engravings, which exhibit the orders of architecture, and other elements of the art, designed for the use of carpenters and builders (1850)
Benjamin, Asher, 1773-1845 · Boston : Benjamin B. Mussey · leaf 76
> TONIC VOLr^TES PL.TTT. Fu) 4 … Fill .1 .»• lOMC VOLUTE. 41 the side of the square 9, 10, 11 and 12, and divide it as is shown ona larger scale at fig. 3; then, with the distance 12 A in your coni-l)asses, and on 12, draw the quarter of a circle A B. Then on 11,and with the distance 11 B, draw the quarter circle B C ; on 10,…
Architecture · Carpentry
