Architectural drawing : a textbook that combines the parctical instructions and examples that the student needs, with the suggestive programs, supplementary problems, etc, required by the teacher, written by an architect of wide experience who has also taught the subject for years at Teachers' College, Columbia University, and Mechanics' Institute, New York (1920)
Teale, Oscar S · New York : U.P.C. Book · leaf 22
uares. (See Fig. 9.) French Curve—A French Curve is a flat form ofcompound curves made in one piece of pear-wood,hard-rubber, celluloid or similar material. The firstnamed are cheapest and best. Their use is to assistin the making of curved lines which cannot be madewith the compass, and which… … Case Instruments—By Case Instruments is meantthe regular set of metal tools provided for use of adraftsman. Every student should, from the beginning,have a set of good instruments, cheap tools are a badinvestment, they are worthless because good workcannot be done with them, even by an expert.…
Architectural drawing
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
