Architectural drawing : a textbook that combines the parctical instructions and examples that the student needs, with the suggestive programs, supplementary problems, etc, required by the teacher, written by an architect of wide experience who has also taught the subject for years at Teachers' College, Columbia University, and Mechanics' Institute, New York (1920)
Teale, Oscar S · New York : U.P.C. Book · leaf 45
especially for class work •Compasses with a spindle or short handle at top are best for handling. 42 ARCHITECTURAL DRAWING (first year) there will be no necessity for using theconical point. Do not puncture the paper with the point if it canpossibly be avoided, such holes are… … FIG. 31 ment cannot be put in proper position a second time,for the purpose of making a second circle or for ink-ing-in the one first drawn. Under such conditions itbecomes almost impossible to successfully join theline of a circle, the finish with the start. And it isequally difficult to make two…
Architectural drawing
