Architectural iron and steel, and its application in the construction of buildings ... specifications of ironwork ... tables selected expressly for this work ... by Wm. H. Birkmire (1905)

Birkmire, Wm. H. (William Harvey), 1860-1924 · New York, J. Wiley · leaf 139

An illustration from Architectural iron and steel, and its application in the construction of buildings ... specifications of ironwork ... tables selected expressly for this work ... by Wm. H. Birkmire, 1905, leaf 139 — tie rod or bolt, the ends on which the nut is screwed areheated and forged thicker ; the thread is then cut on the in-creased diameter. 188. Open-drop Forged Turn-buckles, Pipe Swivel andArm Swivel—are used for tie bars in trusses, etc., with aright and left thread cut in each open end to draw… … •Finished Floor. (-nnisneg.nooc. ; Finish at Ceilino, Elevation ofChute ©r&cket

Building, Iron and steel
