Architectural iron and steel : and its application in the construction of buildings, including beams and girders in floor construction, rolled iron struts, wrought and cast-iron columns, fire-proof columns, column connections, cast-iron lintels, roof trusses, stairways, elevator enclosures, ornamental iron, floor lights, and skylights, vault lights, doors, and shutters, window guards and grilles, etc., etc., with specification of ironwork and selected papers in relation to ironwork, from a revision of the present law before the legislature affecting public interests in the city of New York, in so far as the same regulates the construction of buildings in said city, tables selected expressly for this work, of the properties of beams, channels, tees and angles, used as beams, struts and columns, weights of iron and steel bars, capacity of tanks, areas of circles, weights of circular and square cast-iron columns, weights of substances, tables of squares, cubes, etc., weights of sheet copper, brass and iron, etc (1892)
Birkmire, Wm. H. (William Harvey), 1860-1924 · New York Wiley · leaf 170
n fact made as jagged as possible. 233. Pipe Railing.—For neat, inexpensive and substantialrailings, pipes connected and screwed into couplings are thesimplest. The rails can be bent to any desired pitch and angle.The standards or posts are also of pipe, and are set into andsecured to cast-iron… … as well as bridges. The smaller section, A, is generally appliedto buildings as shown at Fig. i, while the larger section, B, isbetter adapted for bridges, as Fig. 2. * Taken from Pencoyd Iron Works Handbook. i;o ARCHITECTURAL IRON AND STEEL. The following table gives weight per square foot of…
Building, Iron and steel · Building · Ironwork
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
